Condensers

All connections to the pipes are made of steel.

Other connections may be available on request, for the models CRF, CXP, CRM and CXPM, connections are generally available on request.

For the connections of KE and KF condensers:

For normal / industrial water

Connections and shut-off valves for water-cooled condensers for normal / industrial water. The designations and attributions correspond to those in the BITZER price list.
P indicates the variant for hydrocarbons.
S: standard
O: option
*: Option is not available for the P variant (for hydrocarbons).
Condenser	Connection	D10L	D12L	D16L	D22L	D28L	D35L	D42L	D54L	D76L	D108L/ DN100
K033N(P) K033H K073H(P)	Inlet		S: Pipe connection O: Valve*	O: Pipe connection
K033N(P) K033H K073H(P)	Outlet	S: Valve
K123H(P)	Inlet			S: Pipe connection O: Valve*
K123H(P)	Outlet		S: Valve
K203H(P)	Inlet			S: Pipe connection	O: Pipe connection
K203H(P)	Outlet			S: Valve
K283H(P)	Inlet				S: Pipe connection O: Valve*	O: Pipe connection
K283H(P)	Outlet				S: Valve
K373H(P)	Inlet					S: Pipe connection O: Valve*	O: Pipe connection
K373H(P)	Outlet				S: Valve
K573H(P) K813H(P)	Inlet						S: Pipe connection O: Valve*
K573H(P) K813H(P)	Outlet					S: Valve
K1053H(P) K1353T(P)	Inlet							S: Pipe connection O: Valve*
	Outlet						S: Valve O: Pipe connection
	2. outlet						O: Sealing nut O: Pipe connection O: Valve
K1973T(P)	Inlet								S: Bush O: Valve*
	Outlet							S: Valve O: Pipe connection
	2. outlet							O: Sealing nut O: Pipe connection O: Valve
K2923T(P)	Inlet								S: Bush O: Valve*
	Outlet								S: Valve O: Bush
	2. outlet								O: Blind flange O: Bush O: Valve
K3803T(P) K4803T(P)	Inlet									S: Bush O: Valve*
	Outlet									S: Valve O: Bush
	2. outlet									O: Blind flange O: Bush O: Valve
K6703N K6703T K8503N K8503T	Inlet										S: Bush
K6703N K6703T K8503N K8503T	Outlet									S: Valve

Connections and shut-off valves for water-cooled condensers for seawater. The designations and attributions correspond to those in the BITZER price list.
P indicates the variant for hydrocarbons.
S: standard
O: option
*: Option is not available for the P variant (for hydrocarbons).
Condenser	Connection	D10L	D12L	D16L	D22L	D28L	D35L	D42L	D54L	D76L	D108L / DN100
K033NB(P) K033HB K073HB(P)	Inlet		S: Pipe connection O: Valve*	O: Pipe connection
K033NB(P) K033HB K073HB(P)	Outlet	S: Valve
K123HB(P)	Inlet			S: Pipe connection O: Valve*
	Outlet		S: Valve
	2. outlet				S: Sealing nut O: Valve
K203HB(P)	Inlet			S: Pipe connection	O: Pipe connection
	Outlet			S: Valve
	2. outlet				S: Sealing nut O: Valve
K283HB(P)	Inlet				S: Pipe connection O: Valve*	O: Pipe connection
	Outlet				S: Valve
	2. outlet				S: Sealing nut O: Valve
K373HB(P)	Inlet					S: Pipe connection O: Valve*	O: Pipe connection
	Outlet				S: Valve
	2. outlet					S: Sealing nut O: Valve
K573HB(P) K813HB(P)	Inlet						S: Pipe connection O: Valve*
	Outlet					S: Valve
	2. outlet					S: Sealing nut O: Valve
K1053HB(P)	Inlet							S: Pipe connection O: Valve*
	Outlet						S: Valve O: Pipe connection
	2. outlet						S: Sealing nut O: Pipe connection O: Valve
K1353TB(P)	Inlet							S: Pipe connection O: Valve*
	Outlet						S: Valve O: Pipe connection
	2. outlet						S: Sealing nut O: Pipe connection O: Valve
K1973TB(P)	Inlet								S: Bush O: Valve*
	Outlet							S: Valve O: Pipe connection
	2. outlet							S: Sealing nut O: Pipe connection O: Valve
K2923TB(P)	Inlet								S: Bush O: Valve*
	Outlet								S: Valve O: Bush
	2. outlet								S: Blind flange O: Bush O: Valve
K3803TB(P) K4803TB(P)	Inlet									S: Bush O: Valve*
	Outlet									S: Valve O: Bush
	2. outlet									S: Blind flange O: Bush O: Valve
K6703NB K6703TB K8503NB K8503TB	Inlet										S: Bush
	Outlet									S: Valve
	2. outlet									S: Blind flange O: Valve
