Retrofitting CM-RC-02 and configuration with the BEST SOFTWARE
Video mounting instructions
Operating modes
The IQ MODULE offers two operating modes:
- Protection mode (SE-B) - information on installation
- Compressor operation mode - information on installation
By default, the compressor operation mode is activated. The operating mode can be adjusted at any time and the currently set mode can be checked via the BEST SOFTWARE or app.
Relevant documentation
For detailed information and the wiring diagrams for electrical installation, please consult the KT-240 technical information for the compressor module and the AT-300 document on wiring diagrams, which can be found here and under BITZER SOFTWARE.
KT-240 // Technical information: Compressor module for reciprocating compressors IQ MODULE
KT-241-2 // Technical information: Extension board A for compressor module CM-RC-02 of reciprocating compressors IQ MODULE
KT-242-2 // Technical information: Extension board B for compressor module CM-RC-02 of reciprocating compressors IQ MODULE
KB-100-2 // Operating instructions: Semi-hermetic reciprocating compressors
KB-120-9 // Operating instructions: Semi-hermetic reciprocating compressors for subcritical R744 applications
KB-130-9 // Operating instructions: Semi-hermetic reciprocating compressors for transcritical R744 applications
KB-206 // Operating instructions: ECOLITE Air-cooled condensing units with capacity-controlled ECOLINE compressors
AT-300 // Technical information: Schematic wiring diagrams for BITZER products
3D drawings
